The TD-INT-VMEb, powered by an Intel® Xeon D Series – Broadwell DE processor, offers unparalled performance to VME legacy applications to provide ruggedized and highly secure solutions.
The Intel ® Xeon D-1500 family brings the performance of Intel Xeon processor into a dense, low-power system on a chip. With its Intel® 64 Broadwell microarchitecture and its HyperThreading technology, the processing throughput and the application performance are greatly enhanced. Floating point processing is drastically improved by the Advanced Vextor Extension (AVX2) Instruction Set Exten-sion offering an ideal open system for demanding time critical applications.
The TD-INT-VMEb is delivered with its own Boot Loader. This capability to master UEFI firmware allows Tekdense to implement specific functions of services for accurate power-up sequences.
Technical Specification
TD-INT-VMEb - Intel® Xeon® D-15xx VME SBCTECHNOLOGY
-
Processor Unit
- One Intel® Xeon® Processor D-1559 or D-1539 or D-1519
- Core speed = 1.5 GHz for D-1559 and D-1519 ;1.6 GHz for D-1539
- Cache = 18 MB for D-1559 ; 12 MB for D-1539 ; 6MB for D-1519
- Thermal design power = 45W for D-1559 ; 35W for D-1539 ; 25W for D-1519
- DDR4 with ECC (up to 2*8 GB)
- Boot flash memory
- Calendar clock with supercap backup
- Thermal monitor sensor
- On-board SATA SSD (up to 16 GB)
- Up to 4 * SATA ports on P0
- 4 * Gigabit Ethernet ports (1588, Virtualization)
- 4 * USB ports (1 front/ 3 rear)
- 1 * console port (front or rear)
- 3 * multimode serial ports (RS422, RS485, RS232)
- HDMI/DVI output (optional)
- VME64x
- Two PMC/XMC slots(slot 0 compatible with VITA35
- P4V2-64ac . From Pn6 12differential pairs available on
- P2 and up to 8 differential pairs available on P0)
- Open FPGA (Xilinx®Kintex-7) interfaced with up to 80
- differential pairs/ single ended and 4GTP lanes to an
- optional FMC slot
- 6U Rear Transition Module
Storage Sub System
Communication subsystem
I/O subsystem
Accessories
The TD-INT-VMEb is available in air-cooled, and conduction cooled (without front IO) versions compliant with VITA 47 classes.
